Full Specifications

Kode ProdukKB5AG63
Deskripsi ProdukKB5AG63 - Key Selector Switches 3 Position Spring Return Black 1 N/O.
Bezel MaterialPlastic Dark Grey Plastic
Head TypeStandard
Fixing Collar MaterialPlastic
Connections TerminalsScrew clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1
Contact OperationContact operation
Contacts UsageStandard contacts
Positive OpeningWithout
Operating Travel0.1 in (2.6 mm) NO changing electrical state) 0.2 in (4.3 mm) total travel)
Operating Force3.8 N NO changing electrical state
Mechanical Durability1000000 cycles
Contacts MaterialSilver alloy (Ag/Ni)
[Ith] Conventional Free Air Thermal Current10 A IEC 60947-5-1
[Ui] Rated Insulation Voltage600 V (pollution degree 3) conforming to IEC 60947-1
Operator ProfileBlack Key handle



KB5AG63 memberikan kontrol presisi 3 posisi dengan fitur spring return. Menggunakan mekanisme kunci untuk memastikan hanya personel berwenang yang dapat mengoperasikan sistem.


Vinsa

Key Selector Switches 3 Position Spring Return Black 1 N/O

SKU : VINSA-KB5AG63
SALE
15 %
Rp 97,700Rp 83,045
Vinsa - Key Selector Switches 3 Position Spring Return Black 1 N/O - VINSA-KB5AG63
Pilih Kontak





Weight0.07 kg
Dimensions42.00 x 27.00 x 91.00 cm
ColorBlack
DatasheetPDF Key Selector Switches 3 Position Spring Return Black 1 N/O
