Full Specifications
| Kode Produk | C12-220VAC |
| Deskripsi Produk | C12-220VAC - Kontaktor PowerSys Control 3P (12A) 220VAC. |
| [Ue] Rated Operational Voltage | Power circuit: <= 690 V AC 50/60 Hz |
| [Ie] Rated Operational Current | 12 A (AC-3) at Ue = 380/400 V, 50/60 Hz (power circuit) |
| Motor Power (kW) | 4 kW at 380/400 V AC (AC-3), 50/60 Hz |
| Rated Breaking Capacity | According to utilisation category AC-3/AC-4 (IEC 60947-4-1) |
| [Ui] Rated Insulation Voltage | Power circuit: 690 V conforming to IEC 60947-4-1 |
| [Uimp] Rated Impulse Withstand Voltage | 6 kV conforming to IEC 60947 |
| Mechanical Durability | 10,000,000 Mcycles operations |
| [Ith] Conventional Free Air Thermal Current | 25 A |
| Coil Technology | AC electromagnetic coil |
| Control Circuit Voltage Limits | Pick-up: 85% β 110 |
Tingkatkan keamanan panel dengan Kontaktor C12-220VAC. Memiliki kapasitas beban induktif 12A dan beban resistif 20A. Sangat cocok untuk aplikasi mesin industri kecil hingga menengah dengan konfigurasi kontak bantu 1 NO dan 1 NC.
Vinsa
Rp 296,000Rp 251,600
Kontaktor PowerSys Control 3P (12A) 220VAC
SALE
15 %
15 %
Vinsa - Kontaktor PowerSys Control 3P (12A) 220VAC - VINSA-C12-220VAC
Pilih Varian
Kontaktor PowerSys Control 3P (9A) 220VACKontaktor PowerSys Control 3P (12A) 220VACKontaktor PowerSys Control 3P (18A) 220VACKontaktor PowerSys Control 3P (25A) 220VACKontaktor PowerSys Control 3P (32A) 220VACKontaktor PowerSys Control 3P (40A) 220VACKontaktor PowerSys Control 3P (50A) 220VACKontaktor PowerSys Control 3P (65A) 220VACKontaktor PowerSys Control 3P (80A) 220VACKontaktor PowerSys Control 3P (95A) 220VAC
| Weight | 0.35 kg |
|---|---|
| Dimensions | 7.45 x 4.55 x 8.60 cm |
| Color | |
| No. of Poles | 3 P |
| Current Type | AC-3, AC-4 | AC |
| Datasheet |
