Kode Produk	KB2A11DRG
Deskripsi Produk	KB2A11DRG - Illuminated On Off Flush Button Green + Red 220VAC 1 N/O + 1 N/C.
Bezel Material	Plastic
Head Type	Standard
Fixing Collar Material	Plastic
Connections Terminals	Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1
Contact Operation	Slow-break
Contacts Usage	Standard contacts
Positive Opening	Without
Operating Travel	1.5 mm (NC changing electrical state) 2.6 mm (NO changing electrical state) 4.3 mm (total travel)
Operating Force	3.5 N NC changing electrical state 3.8 N NO changing electrical state
Contacts Material	Silver alloy (Ag/Ni)
[Ith] Conventional Free Air Thermal Current	10 A IEC 60947-5-1
[Ui] Rated Insulation Voltage	600 V (pollution degree 3) conf
Operator Profile	Green flush, I (white)



Tingkatkan efisiensi operasional panel Anda dengan Flush Button On Off Illuminated KB2A11DRG. Tombol ini menggabungkan fungsi kontrol On dan Off dalam satu unit ringkas yang dilengkapi dengan lampu indikator. Memiliki warna kontras Hijau dan Merah (Green + Red), memudahkan operator mengidentifikasi status mesin secara visual dengan cepat.
