Full Specifications
| Kode Produk | KB2AA61 |
| Deskripsi Produk | KB2AA61 - Push Button Momentary Blue 1 N/O. |
| Bezel Material | Plastic Dark Grey Plastic |
| Head Type | Standard |
| Fixing Collar Material | Plastic |
| Connections Terminals | Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1 |
| Contact Operation | Slow-break |
| Contacts Usage | Standard contacts |
| Positive Opening | Without |
| Operating Travel | 0.1 in (2.6 mm) NO changing electrical state) 0.2 in (4.3 mm) total travel) |
| Operating Force | 3.8 N NO changing electrical state |
| Mechanical Durability | 1000000 cycles |
| Contacts Material | Silver alloy (Ag/Ni) |
| [Ith] Conventional Free Air Thermal Current | 10 A IEC 60947-5-1 |
| [Ui] Rated Insulation Voltage | 600 V 3)IEC 60947-1 |
| [Uimp] Rated Impulse Withstand Voltage | 6 kV IEC 60947-1 |
| IP Degree Of Protection | IP55 |
| Operator Profile | Blue flush, unmarked |
Tingkatkan fungsionalitas panel kontrol Anda menggunakan Push Button Biru KB2AA61. Dengan mekanisme Spring Return Momentary dan kontak 1 N/O, saklar ini memberikan feedback tactile yang jelas saat dioperasikan. Sangat cocok digunakan sebagai tombol perintah spesifik pada berbagai rangkaian kontrol listrik industri maupun komersial.
Push Button Momentary Blue 1 N/O
