Kode Produk	KB2AD21
Deskripsi Produk	KB2AD21 - Selector Switches 2 Position Stay Put Black 1 N/O.
Bezel Material	Plastic Dark Grey Plastic
Head Type	Standard
Fixing Collar Material	Plastic
Connections Terminals	Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1
Contact Operation	Slow-break
Contacts Usage	Standard contacts
Positive Opening	Without
Operating Travel	0.1 in (2.6 mm) NO changing electrical state) 0.2 in (4.3 mm) total travel)
Operating Force	3.8 N NO changing electrical state
Mechanical Durability	1000000 cycles
Contacts Material	Silver alloy (Ag/Ni)
[Ith] Conventional Free Air Thermal Current	10 A IEC 60947-5-1
[Ui] Rated Insulation Voltage	600 V (pollution degree 3) conforming to IEC 60947-1
Operator Profile	Black standard handle



Selector Switch KB2AD21 adalah sakelar pemilih 2 posisi dengan mekanisme stay put (menetap di posisi). Produk ini hadir dalam balutan warna hitam elegan dan dilengkapi dengan satu kontak Normally Open (1 N/O). Dirancang untuk keandalan maksimal dalam mengontrol berbagai sirkuit listrik pada panel mesin industri.
