Kode Produk	KB2AD41
Deskripsi Produk	KB2AD41 - Selector Switches 2 Position Spring Return Black 1 N/O.
Bezel Material	Plastic Dark Grey Plastic
Head Type	Standard
Fixing Collar Material	Plastic
Connections Terminals	Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1
Contact Operation	Slow-break
Contacts Usage	Standard contacts
Positive Opening	Without
Operating Travel	0.1 in (2.6 mm) NO changing electrical state) 0.2 in (4.3 mm) total travel)
Operating Force	3.8 N NO changing electrical state
Mechanical Durability	1000000 cycles
Contacts Material	Silver alloy (Ag/Ni)
[Ith] Conventional Free Air Thermal Current	10 A IEC 60947-5-1
[Ui] Rated Insulation Voltage	600 V (pollution degree 3) conforming to IEC 60947-1
Operator Profile	Black standard handle



Sakelar pemilih KB2AD41 dirancang khusus untuk aplikasi yang membutuhkan mekanisme spring return (kembali otomatis ke posisi semula) pada sistem 2 posisinya. Memiliki satu kontak 1 N/O dan warna hitam yang profesional, produk ini memastikan operasional kontrol momentary pada panel distribusi listrik berjalan lancar.
