Kode Produk	KB2AD53
Deskripsi Produk	KB2AD53 - Selector Switches 3 Position Spring Return Black 2 N/O.
Bezel Material	Plastic Dark Grey Plastic
Head Type	Standard
Fixing Collar Material	Plastic
Connections Terminals	Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1
Contact Operation	Slow-break
Contacts Usage	Standard contacts
Positive Opening	With conforming to IEC 60947-5-1 appendix K
Operating Travel	0.1 in (2.6 mm) NO changing electrical state) 0.2 in (4.3 mm) total travel)
Operating Force	0.14 N.m NO changing electrical state
Mechanical Durability	1000000 cycles
Contacts Material	Silver alloy (Ag/Ni)
[Ith] Conventional Free Air Thermal Current	10 A IEC 60947-5-1
[Ui] Rated Insulation Voltage	600 V (pollution degree 3) conformi
Operator Profile	Black standard handle



Selector switch KB2AD53 menawarkan kontrol 3 posisi dengan fitur pengoperasian spring return. Menggunakan dua kontak 2 N/O dan warna hitam standar industri, sakelar ini sangat responsif dan dirancang untuk mempermudah operator dalam melakukan pengaturan sirkuit secara cepat dan aman pada sistem kontrol motor atau mesin.
