Kode Produk	KB2AK124M5
Deskripsi Produk	KB2AK124M5 - Illuminated Selector Switches 2 Position Stay Put Red 220VAC 1 N/O.
Bezel Material	Plastic Dark Grey Plastic
Head Type	Standard
Fixing Collar Material	Plastic
Connections Terminals	Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1
Contact Operation	Slow-break
Contacts Usage	Standard contacts
Positive Opening	Without
Operating Travel	0.1 in (2.6 mm) NO changing electrical state) 0.2 in (4.3 mm) total travel)
Operating Force	3.8 N NO changing electrical state
Mechanical Durability	1000000 cycles
Contacts Material	Silver alloy (Ag/Ni)
[Ith] Conventional Free Air Thermal Current	10 A IE
Operator Profile	Red standard handle
Light Source	Universal LED
Bulb Base	Integral LED
Cap/Operator Or Lens Colour	Red



KB2AK124M5 adalah sakelar pemilih 2 posisi stay put yang dilengkapi dengan lampu indikator berwarna merah. Dengan satu kontak 1 N/O, sakelar ini sangat efektif digunakan pada bagian panel yang membutuhkan penanda visual peringatan atau status tertentu yang menonjol agar mudah dipantau oleh operator.
