Kode Produk	KB5AA21
Deskripsi Produk	KB5AA21 - Flush Button Spring Return Memory Black 1 N/O.
Bezel Material	Plastic Dark Grey Plastic
Head Type	Standard
Fixing Collar Material	Plastic
Connections Terminals	Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1
Contact Operation	Slow-break
Contacts Usage	Standard contacts
Positive Opening	Without
Operating Travel	0.1 in (2.6 mm) NO changing electrical state) 0.2 in (4.3 mm) total travel)
Operating Force	3.8 N NO changing electrical state
Mechanical Durability	1000000 cycles
Contacts Material	Silver alloy (Ag/Ni)
[Ith] Conventional Free Air Thermal Current	10 A IEC 60947-5-1
[Ui] Rated Insulation Voltage	600 V 3)IEC 60947-1
[Uimp] Rated Impulse Withstand Voltage	6 kV IEC 60947-1
IP Degree Of Protection	IP55
Operator Profile	Black flush, unmarked



Push Button KB5AA21 warna Hitam (Black) dengan desain Flush Button. Dilengkapi fitur Spring Return Momentary yang otomatis kembali ke posisi semula setelah ditekan. Sangat ideal untuk kontrol panel mesin industrial.
