Kode Produk	KB5AA4342
Deskripsi Produk	KB5AA4342 - Red Flush Button With "STOP" white Marking.
Bezel Material	Plastic Dark Grey Plastic
Head Type	Standard
Fixing Collar Material	Plastic
Connections Terminals	Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1
Contact Operation	Slow-break
Contacts Usage	Standard contacts
Positive Opening	With conforming to IEC 60947-5-1 appendix K
Operating Travel	1.5 mm (NC changing electrical state) 4.3 mm (total travel)
Operating Force	3.5 N NC changing electrical state
Mechanical Durability	1000000 cycles
Contacts Material	Silver alloy (Ag/Ni)
[Ith] Conventional Free Air Thermal Current	10 A IEC 60947-5-1
[Ui] Rated Insulation Voltage	600 V 3)IEC 60947-1
[Uimp] Rated Impulse Withstand Voltage	6 kV IEC 60947-1
Operator Profile	Red flush, “STOP” white marking



Push Button KB5AA4342 warna Merah (Red) yang dilengkapi White Marking "STOP". Memberikan instruksi yang jelas bagi pengguna untuk menghentikan mesin/sistem. Desain Flush hemat tempat dengan kontak 1 N/C.
