Kode Produk	KB5AA51
Deskripsi Produk	KB5AA51 - Flush Button Spring Return Momentary Yellow 1 N/O + 1 N/C.
Bezel Material	Plastic Dark Grey Plastic
Head Type	Standard
Fixing Collar Material	Plastic
Connections Terminals	Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1
Contact Operation	Slow-break
Contacts Usage	Standard contacts
Positive Opening	With conforming to IEC 60947-5-1 appendix K
Operating Travel	1.5 mm (NC changing electrical state) 2.6 mm (NO changing electrical state) 4.3 mm (total travel)
Operating Force	3.5 N NC changing electrical state 3.8 N NO changing electrical state
Mechanical Durability	1000000 cycles
Contacts Material	Silver alloy (Ag/Ni)
[Ith] Conventional Free Air Thermal Current	10 A IEC 60947-5-1
[Ui] Rated Insulation Voltage	600 V 3
Operator Profile	Yellow flush, unmarked



Push Button KB5AA51 hadir dengan kontak ganda 1 N/O + 1 N/C dalam satu unit. Berwarna Kuning (Yellow) dengan desain Flush yang ergonomis dan sistem Spring Return Momentary untuk keamanan operasional mesin.
