Kode Produk	KB5AA61
Deskripsi Produk	KB5AA61 - Flush Button Spring Return Momentary Blue 1 N/O.
Bezel Material	Plastic Dark Grey Plastic
Head Type	Standard
Fixing Collar Material	Plastic
Connections Terminals	Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1
Contact Operation	Slow-break
Contacts Usage	Standard contacts
Positive Opening	Without
Operating Travel	0.1 in (2.6 mm) NO changing electrical state) 0.2 in (4.3 mm) total travel)
Operating Force	3.8 N NO changing electrical state
Mechanical Durability	1000000 cycles
Contacts Material	Silver alloy (Ag/Ni)
[Ith] Conventional Free Air Thermal Current	10 A IEC 60947-5-1
[Ui] Rated Insulation Voltage	600 V 3)IEC 60947-1
[Uimp] Rated Impulse Withstand Voltage	6 kV IEC 60947-1
IP Degree Of Protection	IP55
Operator Profile	Blue flush, unmarked



Push Button KB5AA61 warna Biru (Blue) dengan kontak 1 N/O. Memiliki desain rata (Flush) yang menghemat ruang pada permukaan panel dan sistem Momentary (Spring Return) yang responsif.
