Full Specifications
| Kode Produk | KB5AD33 |
| Deskripsi Produk | KB5AD33 - Selector Switch 3 Position Stay Put 1 N/O + 1 N/C KB5AD33. |
| Bezel Material | Plastic Dark Grey Plastic |
| Head Type | Standard |
| Fixing Collar Material | Plastic |
| Connections Terminals | Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1 |
| Contact Operation | Slow-break |
| Contacts Usage | Standard contacts |
| Positive Opening | With conforming to IEC 60947-5-1 appendix K |
| Operating Travel | 0.1 in (2.6 mm) NO changing electrical state) 0.2 in (4.3 mm) total travel) |
| Operating Force | 0.14 N.m NO changing electrical state |
| Mechanical Durability | 1000000 cycles |
| Contacts Material | Silver alloy (Ag/Ni) |
| [Ith] Conventional Free Air Thermal Current | 10 A IEC 60947-5-1 |
| [Ui] Rated Insulation Voltage | 600 V (pollution degree 3) conforming to IEC 60947-1 |
Tipe KB5AD33 mendukung kontrol 3 posisi yang stabil tanpa kembali otomatis.
Vinsa
Rp 42,000Rp 35,700
Selector Switch 3 Position Stay Put 1 N/O + 1 N/C KB5AD33
SALE
15 %
15 %
Vinsa - Selector Switch 3 Position Stay Put 1 N/O + 1 N/C KB5AD33 - VINSA-KB5AD33
Pilih Jenis
Pilih Kontak
| Weight | 0.08 kg |
|---|---|
| Dimensions | 42.00 x 27.00 x 91.00 cm |
| Color | Black |
| Datasheet |  Selector Switch 3 Position Stay Put 1 N/O + 1 N/C KB5AD33 |
