Full Specifications
| Kode Produk | KB5AK223M5 |
| Deskripsi Produk | KB5AK223M5 - Illuminated Selector Switch 220VAC 3 Stay Put Positions Green 2 N/O. |
| Bezel Material | Plastic Dark Grey Plastic |
| Head Type | Standard |
| Fixing Collar Material | Plastic |
| Connections Terminals | Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1 |
| Contact Operation | Slow-break |
| Contacts Usage | Standard contacts |
| Positive Opening | Without |
| Operating Travel | 0.1 in (2.6 mm) NO changing electrical state) 0.2 in (4.3 mm) total travel) |
| Operating Force | 3.8 N NO changing electrical state |
| Contacts Material | Silver alloy (Ag/Ni) |
| [Ith] Conventional Free Air Thermal Current | 10 A IEC 60947-5-1 |
| Operator Profile | Green standard handle |
| Light Source | Universal LED |
| Bulb Base | Integral LED |
| Cap/Operator Or Lens Colour | Green |
KB5AK223M5 menawarkan kendali 3 arah dengan indikasi lampu hijau terang 220VAC. Menggunakan tipe kontak 1 N/O.
Vinsa
Rp 89,100Rp 75,735
Illuminated Selector Switch 220VAC 3 Stay Put Positions Green 2 N/O
SALE
15 %
15 %
Vinsa - Illuminated Selector Switch 220VAC 3 Stay Put Positions Green 2 N/O - VINSA-KB5AK223M5
Pilih Voltage
| Weight | 0.04 kg |
|---|---|
| Dimensions | 40.00 x 27.00 x 72.00 cm |
| Color | Green |
| Voltage | 220 VAC |
| Datasheet |  Illuminated Selector Switch 220VAC 3 Stay Put Positions Green 2 N/O |
