Full Specifications
| Kode Produk | KB5AS8442 |
| Deskripsi Produk | KB5AS8442 - Emergency Mushroom Push Button Twist Release 1 N/C KB5AS8442. |
| Bezel Material | Plastic Dark Grey Plastic |
| Head Type | Standard |
| Fixing Collar Material | Plastic |
| Connections Terminals | Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1 |
| Contact Operation | Slow-break |
| Contacts Usage | Standard contacts |
| Positive Opening | With conforming to IEC 60947-5-1 appendix K |
| Operating Travel | 1.5 mm (NC changing electrical state) 4.3 mm (total travel) |
| Operating Force | 3.8 N NO changing electrical state |
| Mechanical Durability | 1000000 cycles |
| Contacts Material | Silver alloy (Ag/Ni) |
| [Ith] Conventional Free Air Thermal Current | 10 A IEC 60947-5-1 |
| [Ui] Rated Insulation Voltage | 600 V 3)IEC 60947-1 |
| [Uimp] Rated Impulse Withstand Voltage | 6 kV IEC 60947-1 |
| Operator Profile | Red mushroom Ø 40 mm, unmarked |
Tombol darurat KB5AS8442 dengan kepala jamur merah (mushroom) untuk respon cepat saat kondisi bahaya.
Vinsa
Rp 46,100Rp 39,185
Emergency Mushroom Push Button Twist Release 1 N/C KB5AS8442
SALE
15 %
15 %
Vinsa - Emergency Mushroom Push Button Twist Release 1 N/C KB5AS8442 - VINSA-KB5AS8442
Pilih Jenis
Pilih Kontak
| Weight | 0.06 kg |
|---|---|
| Dimensions | 42.00 x 40.00 x 100.00 cm |
| Color | Red |
| Datasheet |  Emergency Mushroom Push Button Twist Release 1 N/C KB5AS8442 |
