Full Specifications
| Kode Produk | KB5AW34M5 |
| Deskripsi Produk | KB5AW34M5 - Illuminated Push Button 220VAC Protected LEDs Red 1 N/C. |
| Bezel Material | Plastic Dark Grey Plastic |
| Head Type | Standard |
| Fixing Collar Material | Plastic |
| Connections Terminals | Screw clamp terminals, <= 2 x 1.5 mm2 with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 without cable end IEC 60947-1 |
| Contact Operation | Slow-break |
| Contacts Usage | Standard contacts |
| Positive Opening | Without |
| Operating Travel | 1.5 mm (NC changing electrical state) 4.3 mm (total travel) |
| Operating Force | 3.5 N NC changing electrical state |
| Mechanical Durability | 1000000 cycles |
| Contacts Material | Silver alloy (Ag/Ni) |
| [Ith] Conventional Free Air Thermal Current | 10 A IEC 60947-5-1 |
| [Ui] Rated Insulation Voltage | 600 V 3) |
| Operator Profile | Red flush, unmarked |
| Light Source | Universal LED |
| Bulb Base | Integral LED |
| Cap/Operator Or Lens Colour | REd |
Tombol KB5AW34M5 Merah dengan kontak 1 N/C (Normally Closed), sangat tepat digunakan sebagai tombol penghenti yang dilengkapi lampu indikator 220VAC.
Vinsa
Rp 57,700Rp 49,045
Illuminated Push Button 220VAC Protected LEDs Red 1 N/C
SALE
15 %
15 %
Vinsa - Illuminated Push Button 220VAC Protected LEDs Red 1 N/C - VINSA-KB5AW34M5
Pilih Warna
| Weight | 0.04 kg |
|---|---|
| Dimensions | 40.00 x 27.00 x 51.00 cm |
| Color | Red |
| Voltage | 220 VAC |
| Datasheet |  Illuminated Push Button 220VAC Protected LEDs Red 1 N/C |
