Full Specifications
| Kode Produk | M12B3B050 |
| Deskripsi Produk | M12B3B050 - Moulded Case Circuit Breaker (MCCB) 50A 3P. |
| Range Of Product | Basic Series |
| Device Application | Distribution |
| Network Type | AC |
| Network Frequency | 50/60 Hz |
| [Ui] Rated Insulation Voltage | 1000 V AC |
| [Uimp] Rated Impulse Withstand Voltage | 8 kV |
| [Ue] Rated Operational Voltage | 690 V AC |
| Control Type | Toggle |
| Mounting Mode | Fixed |
| Mechanical Durability | 20000 cycles |
| Contact Point | 100% Silver Plated |
| IP Degree Of Protection | IP30 |
| IK Degree Of Protection | IK07 |
| Warranty (In Months) | 12 |
| Standards | IEC 60947-2 & GB/T 14048.2 |
| Trip Unit | Thermal Magnetic |
MCCB Vinsa M12B3B050 50A memberikan perlindungan optimal pada sistem distribusi listrik industri dari risiko arus lebih dan korsleting.
Vinsa
Rp 788,100Rp 669,885
Moulded Case Circuit Breaker (MCCB) 50A 3P
SALE
15 %
15 %
Vinsa - Moulded Case Circuit Breaker (MCCB) 50A 3P - VINSA-M12B3B050
Pilih Varian
Molded Case Circuit Breaker (MCCB) 25A 3PMoulded Case Circuit Breaker (MCCB) 16A 3PMoulded Case Circuit Breaker (MCCB) 20A 3PMoulded Case Circuit Breaker (MCCB) 32A 3PMoulded Case Circuit Breaker (MCCB) 40A 3PMoulded Case Circuit Breaker (MCCB) 50A 3PMoulded Case Circuit Breaker (MCCB) 63A 3PMoulded Case Circuit Breaker (MCCB) 80A 3PMoulded Case Circuit Breaker (MCCB) 100A 3PMoulded Case Circuit Breaker (MCCB) 125A 3PMoulded Case Circuit Breaker (MCCB) M16F3B 160A 3PMoulded Case Circuit Breaker (MCCB) M25F 200A 3PMoulded Case Circuit Breaker (MCCB) M25F 225A 3P 35kAMoulded Case Circuit Breaker (MCCB) M25F 250A 3P 35kAMoulded Case Circuit Breaker (MCCB) M40F 315A 3P 35kAMoulded Case Circuit Breaker (MCCB) M40F 350A 3P 35kAMoulded Case Circuit Breaker (MCCB) M40F 400A 3P 35kAMoulded Case Circuit Breaker (MCCB) M63F 500A 3P 35kAMoulded Case Circuit Breaker (MCCB) M63F 630A 3P 35kAMoulded Case Circuit Breaker (MCCB) M80F 800A 3P 35kA
| Weight | 0.91 kg |
|---|---|
| Dimensions | 13.00 x 7.50 x 5.60 cm |
| Color | |
| No. of Poles | 3 P |
| Rated Current | 50 A |
| Breaking Capacity | 25 kA |
| Voltage | 380/415 V |
| Datasheet |  Moulded Case Circuit Breaker (MCCB) 50A 3P |
