Full Specifications

Kode ProdukC25-220VAC
Deskripsi ProdukC25-220VAC - Kontaktor PowerSys Control 3P (25A) 220VAC.
[Ue] Rated Operational VoltagePower circuit: <= 690 V AC 50/60 Hz
[Ie] Rated Operational Current25 A (AC-3) at Ue = 380/400 V, 50/60 Hz (power circuit)
Motor Power (kW)4 kW at 380/400 V AC (AC-3), 50/60 Hz
Rated Breaking CapacityAccording to utilisation category AC-3/AC-4 (IEC 60947-4-1)
[Ui] Rated Insulation VoltagePower circuit: 690 V conforming to IEC 60947-4-1
[Uimp] Rated Impulse Withstand Voltage6 kV conforming to IEC 60947
Mechanical Durability10,000,000 Mcycles operations
[Ith] Conventional Free Air Thermal Current25 A
Coil TechnologyAC electromagnet



Kontaktor C25-220VAC hadir untuk kebutuhan arus menengah dengan kapasitas 25A pada kategori AC-3. Konstruksi 3 kutub yang kokoh serta tambahan kontak bantu 1 NO + 1 NC memastikan fleksibilitas dalam perakitan panel kontrol listrik Anda.



Vinsa

Kontaktor PowerSys Control 3P (25A) 220VAC

SKU : VINSA-C25-220VAC
SALE
15 %
Rp 452,000Rp 384,200
Vinsa - Kontaktor PowerSys Control 3P (25A) 220VAC - VINSA-C25-220VAC





Weight0.49 kg
Dimensions8.30 x 5.65 x 9.70 cm
Color
No. of Poles3 P
Current TypeAC-3, AC-4 | AC
DatasheetPDF Kontaktor PowerSys Control 3P (25A) 220VAC
